4.16 Terminal Modules
Hardware and Software
200 Service Manual, 03/2011, 6FC5397-5DP40-0BA0
4. Release the protective conductor connection and write the position designation on the
cable.
5. If necessary, unscrew the shield connection.
6. Slide the lug downwards.
7. Swivel the module to the front to remove it.
CAUTION
The 50 mm clearances above and below the components must be observed.
4.16.4 This is how you install a TM54F
Installing
Procedure:
1. Place the components on the mounting rail.
2. Then, swivel the components on the mounting rail so that the mounting catches click into
place at the rear.
3. Slide the components along the mounting rail to either the left or right up to their final
position.
4. Screw on the protective conductor connection.
5. If necessary, screw on the shield connection.
6. Insert the connectors for the digital inputs and outputs at X520 - X535.
7. Insert the DRIVE-CLiQ cables at X500 and X501.
8. Insert the connectors for the sensor and electronics power supply at X514 and X524.
CAUTION
The 50 mm clearances above and below the components must be observed.
