Siemens SINUMERIK 828D Service Manual

Service cases - hardware
4.6 Expansion module NX10.3
Hardware and Software
114 Service Manual, 03/2011, 6FC5397-5DP40-0BA0
7. Now check that all of the cables have been re-connected.
8. Now close the cover cap of the NX10.
9. Close the cabinet and switch-on the system again.
CAUTION
Ensure that all of the connectors and screws are correctly tightened or latched and
inserted.

Siemens SINUMERIK 828D Specifications

General

Control Type	CNC
Operating System	Windows Embedded
Processor	Intel Atom
Display	10.4" color TFT display
Interfaces	Ethernet, USB
Programming	ShopMill, ShopTurn
Operation Panel Size	10.4"
Protection Class	IP65
PLC Memory	2 MB
Spindle Capacity	4 spindles
Hard Drive	CompactFlash
