Siemens SINUMERIK 828D Service Manual

Service cases - hardware
4.8 SINAMICS S120 Combi
Hardware and Software
140 Service Manual, 03/2011, 6FC5397-5DP40-0BA0
Boundary condition
The reinforcement plates must always be installed when operating the S120 Combi with the
external fan unit.
WRONG:
S120 Combi and external fan unit without
reinforcement plates
CORRECT:
S120 Combi and external fan unit with
installed reinforcement plates
CAUTION
Reinforcement plates
Operation without the reinforcement plates is not permissible.
If the reinforcement plates are incorrectly fixed, this can result in an excessively high heat
sink temperature and cause the S120 Combi to prematurely trip.

Siemens SINUMERIK 828D Specifications

General

Control Type	CNC
Operating System	Windows Embedded
Processor	Intel Atom
Display	10.4" color TFT display
Interfaces	Ethernet, USB
Programming	ShopMill, ShopTurn
Operation Panel Size	10.4"
Protection Class	IP65
PLC Memory	2 MB
Spindle Capacity	4 spindles
Hard Drive	CompactFlash
