Service cases - hardware
4.14 Sensor Modules Cabinet
Hardware and Software
186 Service Manual, 03/2011, 6FC5397-5DP40-0BA0
NOTICE
Electro-static discharge (ESD)
Before you touch the module, discharge yourself at the cabinet or at the ground terminal.
Procedure:
1. Before withdrawing it, label the connector X524 for the electronics power supply.
2. Screw on the encoder connecting cable to X520 or X521 / X531, if required, also the
shield connection.
3. Release the protective conductor connection and write the position designation on the
cable.
4. Slide the lug downwards.
5. Swivel the module to the front to remove it.
CAUTION
The 50 mm clearances above and below the components must be observed.
