Siemens SINUMERIK 828D Service Manual

Service cases - hardware
4.15 Sensor Modules External
Hardware and Software
Service Manual, 03/2011, 6FC5397-5DP40-0BA0
195
Installing
Procedure:
1. Now install the new SME125 module.
2. Screw on the protective conductor connection.
3. Reconnect the temperature sensor at X200.
4. Reconnect the encoder connecting cable.
5. Connect the DRIVE-CLiQ cable.
CAUTION
The maximum DRIVE-CLiQ cable length is 100 m.
The maximum encoder cable length is 3 m.
In order to guarantee the degree of protection, all of the plug connectors must be
correctly screwed and snapped into place.

Siemens SINUMERIK 828D Specifications

General

Control Type	CNC
Operating System	Windows Embedded
Processor	Intel Atom
Display	10.4" color TFT display
Interfaces	Ethernet, USB
Programming	ShopMill, ShopTurn
Operation Panel Size	10.4"
Protection Class	IP65
PLC Memory	2 MB
Spindle Capacity	4 spindles
Hard Drive	CompactFlash
