Service cases - software
3.2 Generating a commissioning archive
Hardware and Software
Service Manual, 03/2011, 6FC5397-5DP40-0BA0
33
Note
Easy Archive
Select all of the components, unless it is known that individual components do not
deviate from the Siemens standard.
Select all data classes, unless only certain data (e.g. INDIVIDUAL) are to be backed
up.
6. Press the "Generate archive" softkey.
The "Generate Archive: Select Archive" window opens.
7. Select the storage location of the archive:
"Archives": Internal memory on the CompactFlash Card system
8. Select a directory.
Example: "Archives" → "Manufacturer"
- OR -
9. Press the "New directory" softkey to generate a new directory.
The "New Directory" window opens.
10. Enter the required name and confirm with "OK."
The directory is created subordinate to the selected folder.
11. Press the "OK" softkey.
The "Generate Archive: Name" window opens.
12. Enter the required name and confirm with "OK."
A file with the ARD format type is saved in the selected directory.
