Siemens SINUMERIK 840D sl Operation/Programming

3
Machining the Workpiece 08/2005
3.7 Overstorin
g
3
© Siemens AG, 2005. All rights reserved
3-104 SINUMERIK 840D sl Operation/Programming ShopTurn (BAT) – 08/2005 Edition
After "Overstore", a subroutine with the content REPOSA, which you
can observe, is executed.
Overstore without single
block
 Load a program in "Machine Auto" operating mode (see Sec.
"Selecting a program for execution").
Cycle Stop
 Press the "Cycle Stop" key.
 Press the "Overstore" softkey.
The "Overstore" window is opened.
 Enter the NC blocks to be processed.
Cycle Start
 Press the "Cycle Start" key.
The blocks you have entered are stored. You can observe execution
of the blocks in the "Overstore" window.
After the entered blocks have been executed, you can append blocks
again.
Stopping overstore
 Press the "Back" key to exit "Overstore".
The window is closed.
You can switch modes now.
Cycle Start
After you have pressed "Cycle Start" again, the selected program
continues before overstore.

Siemens SINUMERIK 840D sl Specifications

General

Control Type	CNC
Number of Axes	Up to 31
Max Number of Channels	10
Interfaces	Ethernet, PROFIBUS, PROFINET, USB
Interpolation	5-axis interpolation
Operating Temperature	0°C to 45°C
Relative Humidity	Up to 95% (non-condensing)
Display	TFT color display, various sizes
Programming Languages	DIN/ISO
Safety Features	Safety Integrated
PLC	Integrated PLC S7-300
Drive Interface	SINAMICS S120
Data Storage	CF card, USB
Operating System	Windows-based
