Siemens SINUMERIK 840D sl Operation/Programming

4
08/2005 Creating a ShopTurn Program
4
♥ Siemens AG, 2005. All rights reserved
SINUMERIK 840D sl Operation/Programming ShopTurn (BAT) – 08/2005 Edition 4-147
4.3.4 Changing program blocks
You can later optimize the parameters in the programmed ShopTurn
blocks or adapt them to new situations, e.g. if you want to increase the
feedrate or shift a position. In this case, you can change all the
parameters in every program block directly in the associated
parameter screen form.
 Press the "Program" softkey.
The directory overview is displayed.
 Place the cursor on the directory that contains the program that
you want to open.
-or-
 Press the "Input" or "Cursor Right" key.
All the programs in this directory are displayed.
 Select the program that you want to change.
-or-
 Press the "Input" or "Cursor Right" key.
The machining plan of the program is displayed.
 Place the cursor on the desired program block in the machining
plan.
 Press the "Cursor Right" key.
The parameter screen for the selected program block appears.
 Make the desired changes.
-or-
 Press the "Accept" softkey or the "Cursor left" key.
The changes are accepted in the program.

Siemens SINUMERIK 840D sl Specifications

General

Control Type	CNC
Number of Axes	Up to 31
Max Number of Channels	10
Interfaces	Ethernet, PROFIBUS, PROFINET, USB
Interpolation	5-axis interpolation
Operating Temperature	0°C to 45°C
Relative Humidity	Up to 95% (non-condensing)
Display	TFT color display, various sizes
Programming Languages	DIN/ISO
Safety Features	Safety Integrated
PLC	Integrated PLC S7-300
Drive Interface	SINAMICS S120
Data Storage	CF card, USB
Operating System	Windows-based
