Siemens SINUMERIK 840D sl Operation/Programming

A
Appendix 08/2005
A Abbreviations
A
♥ Siemens AG, 2005. All rights reserved
A-430 SINUMERIK 840D sl Operation/Programming ShopTurn (BAT) – 08/2005 Edition
A Abbreviations
ABS
Absolute dimensions
CNC
Computerized Numerical Control
COM
Communication
Component of NC control that performs and coordinates
communication.
D
Cutting edge
DIN
German Industry Standard (Deutsche Industrie Norm)
DRF
Differential Resolver Function
The function in conjunction with an electronic handwheel generates an
incremental work offset in automatic mode.
DRY
DRY run: Dry run feedrate
F
Feedrate
GUD
Global User Data
INC
Increment
INI
INItializing data
INK
Incremental dimensions
LED
Light Emitting Diode
M01
M function: Programmed stop
MCS
Machine Coordinate System
MD
Machine data
MDA
Manual Data Input
MPF
Main Program File
NC
Numerical Control
The NC control comprises the components NCK, PLC, PCU and
COM.

Siemens SINUMERIK 840D sl Specifications

General

Control Type	CNC
Number of Axes	Up to 31
Max Number of Channels	10
Interfaces	Ethernet, PROFIBUS, PROFINET, USB
Interpolation	5-axis interpolation
Operating Temperature	0°C to 45°C
Relative Humidity	Up to 95% (non-condensing)
Display	TFT color display, various sizes
Programming Languages	DIN/ISO
Safety Features	Safety Integrated
PLC	Integrated PLC S7-300
Drive Interface	SINAMICS S120
Data Storage	CF card, USB
Operating System	Windows-based
