Siemens SINUMERIK 840D sl Operation/Programming

6
Working with Manual Machine 08/2005
6.3 Sim
p
le work
p
iece machinin
g
in manual mode
6
♥ Siemens AG, 2005. All rights reserved
6-336 SINUMERIK 840D sl Operation/Programming ShopTurn (BAT) – 08/2005 Edition
6.3.1 Traversing the axes
For preparatory actions and simple traversing movements, input the
parameters directly into the "Manual" basic screen form.
Tool selection
 Select the desired tool in "T".
 Input the feedrate and the spindle speed.
 Select the direction of spindle rotation.
-or-
 Set the direction of rotation via the machine control panel.
 Press the "Cycle Start" key.
The spindle starts immediately after the tool is selected.
Please also refer to the machine manufacturer's instructions.
Machining
X
…
 Select the axis to be traversed at the machine control panel.
…
+
 Press the "-" or "+" key on the machine control panel.
-or-
 Select the direction with the aid of the cross-switching lever.
The axes are moved at the set machining feedrate.
Please also refer to the machine manufacturer's instructions.
The active direction is graphically displayed in the basic screen by
means of a wind rose.

Siemens SINUMERIK 840D sl Specifications

General

Control Type	CNC
Number of Axes	Up to 31
Max Number of Channels	10
Interfaces	Ethernet, PROFIBUS, PROFINET, USB
Interpolation	5-axis interpolation
Operating Temperature	0°C to 45°C
Relative Humidity	Up to 95% (non-condensing)
Display	TFT color display, various sizes
Programming Languages	DIN/ISO
Safety Features	Safety Integrated
PLC	Integrated PLC S7-300
Drive Interface	SINAMICS S120
Data Storage	CF card, USB
Operating System	Windows-based
