2
Setting Up the Machine 08/2005
2.2 A
roachin
the reference
oint
2
♥ Siemens AG, 2005. All rights reserved
2-48 SINUMERIK 840D sl Operation/Programming ShopTurn (BAT) – 08/2005 Edition
2.2.1 User agreement for Safety Integrated
If you are using Safety Integrated (SI) on your machine, you will need
to confirm that the current displayed position of an axis corresponds to
its actual position on the machine when you reference an axis. Your
confirmation is the precondition for the availability of other Safety
Integrated functions.
You can only give your user agreement for an axis after it has
approached the reference point.
The displayed axis position always refers to the machine coordinate
system (MCS = machine).
User agreement with Safety Integrated is only possible with a software
option.
For more information on user agreement, please refer to:
References: /FBSI/, Description of Functions SINUMERIK Safety
Integrated
Jog
Select "Machine Manual" mode.
Ref Point
Press the "Ref Point" key on the machine control panel.
X
…
Select the axis to be traversed.
…
+
Press the "-" or "+" key.
Your selected axis moves to the reference point and stops. The
coordinate of the reference point is displayed. The axis is marked with
.
If an axis key in the wrong direction is selected, the axis does not
move.
User
Agreement
Press the "User Agreement" softkey.
The "User agreement" window opens.
It shows a list of all machine axes with their current and SI positions.
Position the cursor in the "Agreement" field for the axis in
question.
-or-
Give your agreement by pressing the "Alternat." softkey or the
"Select" key.
The selected axis is marked with a cross meaning "safely referenced"
in the "Agreement" column.
By pressing the "toggle keys," you again deactivate the agreement.
