Siemens SINUMERIK 840D sl Operation/Programming

4
Creating a ShopTurn Program 08/2005
4
♥ Siemens AG, 2005. All rights reserved
4-150 SINUMERIK 840D sl Operation/Programming ShopTurn (BAT) – 08/2005 Edition
Find
Search
>
 Press the "Search" softkey.
 Enter a block number or text.
 Select whether the search is to commence at the start of the
program or the current cursor position.
Search

Press the "Search" softkey.
ShopTurn searches throughout the program. The cursor highlights the
search hit.
Find
next
 Press the "Find next" softkey to continue the search, as
necessary.
Contour: Renaming
 Place the cursor on a contour in the machining plan.
Rename
 Press the "Rename" softkey.
 Enter a new name for the contour.
 Press the "OK" softkey.
The name of the contour is changed and displayed in the machining
plan.
Numbering program
blocks
Renumber
 Press the "Renumber" softkey.
The program blocks are renumbered in ascending order.
Closing the program
editor
 Press the "Back" softkey to close the program editor.

Siemens SINUMERIK 840D sl Specifications

General

Control Type	CNC
Number of Axes	Up to 31
Max Number of Channels	10
Interfaces	Ethernet, PROFIBUS, PROFINET, USB
Interpolation	5-axis interpolation
Operating Temperature	0°C to 45°C
Relative Humidity	Up to 95% (non-condensing)
Display	TFT color display, various sizes
Programming Languages	DIN/ISO
Safety Features	Safety Integrated
PLC	Integrated PLC S7-300
Drive Interface	SINAMICS S120
Data Storage	CF card, USB
Operating System	Windows-based
