SINUMERIK 840D sl Operation/Programming ShopTurn (BAT) – 08/2005 Edition 5-157
¾ Choose one of the machining planes (Rotate,
End face/End face C, Peripheral surface/Peripheral surface C,
End face Y or Peripheral surface Y).
¾ Enter the cylinder diameter if you selected the machining plane
Peripheral surface/Peripheral surface C.
-or-
¾ Enter the positioning angle for the CP machining area if you
selected machining plane End face Y.
-or-
¾ Enter reference point C0 if you selected the machining plane
Peripheral surface Y.
¾ Choose whether the spindle should be clamped or released or
whether there should be no change (input field left blank).
¾ Press the "Accept" softkey.
The values are saved and the parameterization screen form is closed.
The process plan is displayed and the newly created program block is
marked.

Siemens SINUMERIK 840D sl Specifications

General

Control Type	CNC
Number of Axes	Up to 31
Max Number of Channels	10
Interfaces	Ethernet, PROFIBUS, PROFINET, USB
Interpolation	5-axis interpolation
Operating Temperature	0°C to 45°C
Relative Humidity	Up to 95% (non-condensing)
Display	TFT color display, various sizes
Programming Languages	DIN/ISO
Safety Features	Safety Integrated
PLC	Integrated PLC S7-300
Drive Interface	SINAMICS S120
Data Storage	CF card, USB
Operating System	Windows-based
