Siemens SINUMERIK 840D sl Operation/Programming

5
08/2005 ShopTurn Functions
5.1 Strai
g
ht or circular
p
ath movements
5
♥ Siemens AG, 2005. All rights reserved
SINUMERIK 840D sl Operation/Programming ShopTurn (BAT) – 08/2005 Edition 5-159
Straight >
¾ Press the "Strai. Circle" and "Straight" softkeys.
Rapide
traverse
¾ Press the "Rapid traverse" soft key if you want to use rapid
traverse instead of a programmed machining feedrate.
Parameters Description Unit
X
Z
Y
C1
C3
Z3
Target position in the X direction (abs or inc)
Incremental dimensions: The plus/minus sign is evaluated.
Target position in the Z direction (abs or inc)
Incremental dimensions: The plus/minus sign is evaluated.
Target position in the Y direction (abs or inc)
Incremental dimensions: The plus/minus sign is evaluated.
Target position of C axis of main spindle (abs or inc)
Incremental dimensions: The plus/minus sign is evaluated.
Target position of C axis of counterspindle (abs or inc)
Incremental dimensions: The plus/minus sign is evaluated.
Target position of special axis (abs or inc)
Incremental dimensions: The plus/minus sign is evaluated.
mm
mm
mm
mm
mm
mm
F Machining feedrate mm/rev
mm/min
mm/tooth
Radius
compensation
Input defining which side of the contour the tool machines in the programmed
direction:
Radius compensation to right of contour
Radius compensation to left of contour
Radius compensation off
The previously programmed setting for radius compensation is used

Siemens SINUMERIK 840D sl Specifications

General

Control Type	CNC
Number of Axes	Up to 31
Max Number of Channels	10
Interfaces	Ethernet, PROFIBUS, PROFINET, USB
Interpolation	5-axis interpolation
Operating Temperature	0°C to 45°C
Relative Humidity	Up to 95% (non-condensing)
Display	TFT color display, various sizes
Programming Languages	DIN/ISO
Safety Features	Safety Integrated
PLC	Integrated PLC S7-300
Drive Interface	SINAMICS S120
Data Storage	CF card, USB
Operating System	Windows-based
