Siemens SINUMERIK 840D sl Operation/Programming

5
08/2005 ShopTurn Functions
5.3 Turnin
g
5
♥ Siemens AG, 2005. All rights reserved
SINUMERIK 840D sl Operation/Programming ShopTurn (BAT) – 08/2005 Edition 5-209
Part >
¾ Press the "Turning" and "Part" soft keys.
Parameters Description Unit
T, D, F, S, V See Sec. "Creating program blocks".
SV Speed limit for constant cutting rate (with V only) rpm
X0
Reference point ¬ (abs)
mm
Z0 Reference point (abs) mm
FS Chamfer alternative to R mm
R Radius alternative to FS mm
X1
Depth for feedrate reduction ¬ (abs) or depth for feedrate reduction (inc)
mm
FR Reduced feedrate mm/rev
SR Reduced speed of rotation rpm
Parts gripper Yes: Extend workpiece drawer
No: Do not extend workpiece drawer
XM Depth to which the drawer must be extended (abs) mm
X2
Final depth ¬ (abs) or final depth (inc)
mm

Siemens SINUMERIK 840D sl Specifications

General

Control Type	CNC
Number of Axes	Up to 31
Max Number of Channels	10
Interfaces	Ethernet, PROFIBUS, PROFINET, USB
Interpolation	5-axis interpolation
Operating Temperature	0°C to 45°C
Relative Humidity	Up to 95% (non-condensing)
Display	TFT color display, various sizes
Programming Languages	DIN/ISO
Safety Features	Safety Integrated
PLC	Integrated PLC S7-300
Drive Interface	SINAMICS S120
Data Storage	CF card, USB
Operating System	Windows-based
