08/2005 ShopTurn Functions
5.5 Millin
5
♥ Siemens AG, 2005. All rights reserved
SINUMERIK 840D sl Operation/Programming ShopTurn (BAT) – 08/2005 Edition 5-249
FS
ZFS
Chamfer width (inc) (for chamfer only)
Insertion depth of tool tip (abs or inc) -- (for chamfer only)
mm
mm
CP
X0
Y0
L0
C0
Z0
Z1
DZ
UXY
UZ
FS
ZFS
Single position End face Y:
The reference point is always the center point of the circular spigot.
Positioning angle for machining area
Reference point in X direction (abs.)
Reference point in Y direction (abs.)
Reference point on longitudinal polar axis (alternative to X0)
Reference point on angular polar axis (alternative to Y0)
Reference point in Z direction (abs.)
Spigot depth based on Z0 (abs or inc) – (only for roughing and finishing)
Maximum depth infeed (Z direction) – (for roughing and finishing only)
Finishing allowance in the plane (spigot edge) – (for roughing and finishing only)
Finishing allowance in depth (spigot base) – (for roughing and finishing only)
Chamfer width (inc) (for chamfer only)
Insertion depth of tool tip (abs or inc) -- (for chamfer only)
Degrees
mm
mm
mm
Degrees
mm
mm
mm
mm
mm
mm
mm
C0
Y0
Z0
X0
X1
DX
UYZ
UX
FS
ZFS
Single position Peripheral surface Y:
The reference point is always the center point of the circular spigot.
Reference point
Reference point in Y direction (abs.)
Reference point in Z direction (abs.)
Reference point in X direction (abs.)
Spigot depth based on X0 (abs or inc) – (only for roughing and finishing)
Maximum depth infeed (X direction) – (for roughing and finishing only)
Finishing allowance in the plane (spigot edge) – (for roughing and finishing only)
Finishing allowance in depth (spigot base) – (for roughing and finishing only)
Chamfer width (inc) (for chamfer only)
Insertion depth of tool tip (abs or inc) -- (for chamfer only)
Degrees
mm
mm
mm
mm
mm
mm
mm
mm
mm
¬
Diameter of finished-part spigot mm
¬1
Diameter of blank spigot (important for determining approach position) mm
