Siemens SINUMERIK 840D sl Operation/Programming

5
ShopTurn Functions 08/2005
5.6 Contour millin
g
5
♥ Siemens AG, 2005. All rights reserved
5-280 SINUMERIK 840D sl Operation/Programming ShopTurn (BAT) – 08/2005 Edition
α1
α2
⇓1
⇓2
Incremental dimensions: The plus/minus sign is evaluated.
Starting angle to Y axis
Angle to preceding element
Tangential transition: α2=0
End angle to Y axis
Angle of aperture of circle
Degrees
Degrees
Degrees
Degrees
Y
Z
J
K
α1
α2
⇓1
⇓2
Peripheral surface Y - Cartesian:
End point in the Y direction (abs. or inc.)
Incremental dimensions: The plus/minus sign is evaluated.
End point in the Z direction (abs. or inc.)
Incremental dimensions: The plus/minus sign is evaluated.
Circle center point in Y direction (abs. or inc.)
Incremental dimensions: The plus/minus sign is evaluated.
Circle center point in Z direction (abs. or inc.)
Incremental dimensions: The plus/minus sign is evaluated.
Starting angle to Y axis
Angle to preceding element
Tangential transition: α2=0
End angle to Y axis
Angle of aperture of circle
mm
mm
mm
mm
Degrees
Degrees
Degrees
Degrees
Transition to
following
element
FS: Chamfer as transition element to next contour element
R: Radius as transition element to next contour element
mm
mm
Additional
command
Any additional command in G code format
