7
G Code Program 08/2005
7.1 Creatin
g
a G-code
p
ro
g
ram
7
Siemens AG, 2005. All rights reserved
7-346 SINUMERIK 840D sl Operation/Programming ShopTurn (BAT) – 08/2005 Edition
Edit
Select the "Edit" softkey if you want to return directly to the G code
editor from a parameter screen form.
Measuring cycle support
Switch to the extended horizontal softkey bar.
Measure
turning
-or-
Measure
milling
Press the "Measure turning" or "Measure milling".
Calibrate
meas. cal.
...
Select the required measuring cycle via the softkey.
Enter the parameters.
OK
Press the "OK" softkey.
The measuring cycle is transferred to the editor as G code.
Position the cursor on a measuring cycle in the G code editor, if
you want to display the associated parameter screen form again.
Re-
compile
Select the "Recompile" softkey.
The parameter screen for the selected measuring cycle appears.
Edit
Select the "Edit" softkey if you want to return directly to the G code
editor from a parameter screen form.
Online help (PCU 50.3)
Place the cursor on a G code command in the G code editor or on
an input field in a cycle support parameter screen form.
Press the "Help" key.
The relevant help screen is displayed.
