Siemens SINUMERIK 840D sl Operation/Programming

7
G Code Program 08/2005
7.3 G-code editor
7
♥ Siemens AG, 2005. All rights reserved
7-350 SINUMERIK 840D sl Operation/Programming ShopTurn (BAT) – 08/2005 Edition
G code: Copying
 Select the G code that you want to copy.
Copy
 Press the "Copy" softkey.
The G code is stored in buffer memory and remains there even if you
switch to another program.
G code: Pasting
 Copy the G code that you want to insert.
Insert
 Press the "Insert" softkey.
The copied G code is pasted from buffer memory into the text in front
of the cursor.
G code: Cutting
 Select the G code that you want to cut.
Cut
 Press the "Cut" softkey.
The selected G code is removed and stored in buffer memory.
G code: Find
Search
 Press the "Search" softkey.
A new vertical softkey bar appears.
 Enter the character string that you want to locate.
 Press the "OK" softkey.
The G code program is searched for the character string in the
forward direction. The character string is marked in the editor by the
cursor.
Find next
 Press the "Find next" softkey to continue the search, as
necessary.
The next character string found is displayed.

Siemens SINUMERIK 840D sl Specifications

General

Control Type	CNC
Number of Axes	Up to 31
Max Number of Channels	10
Interfaces	Ethernet, PROFIBUS, PROFINET, USB
Interpolation	5-axis interpolation
Operating Temperature	0°C to 45°C
Relative Humidity	Up to 95% (non-condensing)
Display	TFT color display, various sizes
Programming Languages	DIN/ISO
Safety Features	Safety Integrated
PLC	Integrated PLC S7-300
Drive Interface	SINAMICS S120
Data Storage	CF card, USB
Operating System	Windows-based
