Siemens SINUMERIK 840D sl - Page 357

8
08/2005 Tool Management
8.1 Tool lists
,
tool wear lists and the tool ma
g
azine
8
© Siemens AG, 2005. All rights reserved
SINUMERIK 840D sl Operation/Programming ShopTurn (BAT) – 08/2005 Edition 8-357
Multifix
If you use a multifix tool holder, the tool list looks like the following:
Tool list for a multifix tool holder
If you use multifix tool holders, the tool change takes place manually,
i.e. the tools are swapped in and out by hand.
Tool selection for multifix
tool holders
Tool
selection
In the tool list, select the desired tool and activate it (the values of the
tool) with the aid of the “Tool selection“ softkey.
