8
Tool Management 08/2005
8.5 Loadin
/unloadin
a tool into/out of the ma
azine
8
♥ Siemens AG, 2005. All rights reserved
8-366 SINUMERIK 840D sl Operation/Programming ShopTurn (BAT) – 08/2005 Edition
-or-
Enter the location number you require and press the "OK" softkey.
-or-
Spindle
Press the "Spindle" and "OK" softkeys to load a tool into the
spindle.
The tool is loaded into the specified magazine location.
Finding an empty
location in the magazine
and loading the tool
Select the "Tool list" softkey in the "Tools WOs" operating area.
Place the cursor on the tool that you want to load into the
magazine.
Load
Press the "Load" softkey.
The "Empty location" window appears. The "Location" field is
initialized with the number of the first empty magazine location.
Enter the magazine number and a "0" for the location number if
you wish to search for an empty location in a particular magazine.
-or-
Enter a "0" for the magazine number and location number if you
wish to search for an empty location in all magazines.
Press the "OK" softkey.
An empty location is suggested.
Press the "OK" softkey.
The tool is loaded into the suggested magazine location.
Unloading an individual
tool from the magazine
Select the "Tool list" softkey in the "Tools WOs" operating area.
Position the cursor on the tool that you want to unload.
Unload
Press the "Unload" softkey.
The tool is unloaded from the magazine.
