Siemens SINUMERIK 840D sl Operation/Programming

9
Program Management 08/2005
9.2 Mana
g
in
g
p
ro
g
rams with Sho
p
Turn on NCU
(
HMI Embedded
)
9
♥ Siemens AG, 2005. All rights reserved
9-386 SINUMERIK 840D sl Operation/Programming ShopTurn (BAT) – 08/2005 Edition
 Select the "No" softkey if you want to keep the old tool.
If the old tool is not at the saved magazine location, it is relocated
there.
-or-
 Select the "Yes" softkey if you want to overwrite the old tool.
With the tool management option without loading/unloading, the old
tool is deleted; the old tool is unloaded beforehand in the variant with
loading/unloading.
If you change the tool name before importing it with "Yes", the tool will
be added as an extra tool to the tool list.
Work offsets
Existing work offsets are always overwritten when new offsets are
imported.
Magazine loading
If magazine loading data are not imported at the same time, tools are
entered in the tool list without a location number.

Siemens SINUMERIK 840D sl Specifications

General

Control Type	CNC
Number of Axes	Up to 31
Max Number of Channels	10
Interfaces	Ethernet, PROFIBUS, PROFINET, USB
Interpolation	5-axis interpolation
Operating Temperature	0°C to 45°C
Relative Humidity	Up to 95% (non-condensing)
Display	TFT color display, various sizes
Programming Languages	DIN/ISO
Safety Features	Safety Integrated
PLC	Integrated PLC S7-300
Drive Interface	SINAMICS S120
Data Storage	CF card, USB
Operating System	Windows-based
