Siemens SINUMERIK 840D sl Operation/Programming

9
08/2005 Program Management
9.3 Mana
g
in
g
p
ro
g
rams with PCU 50.3
(
HMI Advanced
)
9
© Siemens AG, 2005. All rights reserved
SINUMERIK 840D sl Operation/Programming ShopTurn (BAT) – 08/2005 Edition 9-393
Executing a G-code
program from the
diskette/USB/network-drive
 Open the Program Manager.
...
 Via the softkey, select the diskette/USB/network-drive or local
USB port.
 Place the cursor on the directory that contains the G code
program you want to execute.
-or-
 Press the "Input" or "Cursor right" key.
The directory opens.
 Place the cursor on the G code program you want to execute.
Continue
>
Execute
HD
 Select the "Continue" and "Execute HD" softkeys.
ShopTurn now switches to "Machine Auto" mode and loads the G-
code program.
Cycle Start
 Press the "Cycle Start" key.
The machining of the workpiece is started (see Sec. "Machining a
workpiece".) The program contents are continuously reloaded into the
NCK work memory as the machining progresses.

Siemens SINUMERIK 840D sl Specifications

General

Control Type	CNC
Number of Axes	Up to 31
Max Number of Channels	10
Interfaces	Ethernet, PROFIBUS, PROFINET, USB
Interpolation	5-axis interpolation
Operating Temperature	0°C to 45°C
Relative Humidity	Up to 95% (non-condensing)
Display	TFT color display, various sizes
Programming Languages	DIN/ISO
Safety Features	Safety Integrated
PLC	Integrated PLC S7-300
Drive Interface	SINAMICS S120
Data Storage	CF card, USB
Operating System	Windows-based
