Setting Up the Machine 08/2005
2.5 Tools
2
♥ Siemens AG, 2005. All rights reserved
2-58 SINUMERIK 840D sl Operation/Programming ShopTurn (BAT) – 08/2005 Edition
Plate length
Radius
Plate width
Length X
Length Z
Recessing tool
Length X
Length Z
Diameter
Milling tool
Length X
Diameter
Length Z
Tip angle
Drill
Length X
Length Z
Radius
Threading tool
