Detailed description
2.7 Program operation mode
Basic logic functions: Mode group, channel, program operation, reset response (K1)
116 Function Manual, 11/2006, 6FC5397-0BP10-2BA0
Event
Part program end
Table 2-7 Sequence at part program end
Sequence Command Boundary conditions
(must be satisfied before the
command)
Comments
1 Channel selection:
Active status
Mode selection:
AUTO or
AUTO and overstoring or
MDA or TEACHIN
Initial state specification:
Channel in Active status
mode:
AUTO or
AUTO and overstoring or
MDA or TEACHIN
Select channel and mode,
channel: in active status and
mode: as per selection
2 NC Start Block with end of part program Block is changed
3 MD20110 $MC_
RESET_MODE_MASK,
MD20150 $MC_
GCODE_RESET_VALUES,
MD20152 $MC_
GCODE_RESET_MODE
Control activated:
Reset sequence with evaluation
Control enabled
Reset sequence with evaluation
of MD 20110 and MD 20150 and
MD 20152
4 /_N_CMA_DIR/_N_PROG_
EVENT_SPF or name from
MD11620
as an ASUB Implied call of the path name as
an ASUB
5 MD20110 $MC_
RESET_MODE_MASK,
MD20150 $MC_
GCODE_RESET_VALUES,
MD20152 $MC_
GCODE_RESET_MODE
Control activated:
Reset sequence with evaluation
Control activated
Reset sequence with evaluation
of MD20110 and MD20150 and
MD20152. Significance:
The G-code indexed position
continues to be specified with
machine data
