Siemens SINUMERIK 840D

Detailed description
2.7 Program operation mode
Basic logic functions: Mode group, channel, program operation, reset response (K1)
Function Manual, 11/2006, 6FC5397-0BP10-2BA0
117
Event
Operator panel reset
Table 2-8 Processing sequence in operator panel reset
Sequence Command Boundary conditions
(must be satisfied before the
command)
Comments
1 Selection of channel and mode:
any
Initial state: Any mode, any
channel status
Select mode / channel status
from
any state
2 Reset
3 MD20110 $MC_
RESET_MODE_MASK,
MD20150 $MC_
GCODE_RESET_VALUES,
MD20152 $MC_
GCODE_RESET_MODE
Control activated:
Reset sequence with evaluation
Control activated
Reset sequence with evaluation
of MD20110 and MD20150 and
MD20152
4 /_N_CMA_DIR/_N_PROG_
EVENT_SPF or name from
MD11620
as an ASUB Implied call of the path name as
an ASUB
5 MD20110 $MC_
RESET_MODE_MASK,
MD20150 $MC_
GCODE_RESET_VALUES,
MD20152$MC_
GCODE_RESET_MODE
Control activated:
Reset sequence with evaluation
Control activated
Reset sequence with evaluation
of MD20110 and MD20150 and
MD20152. Significance:
The G-code indexed position
continues to be specified with
machine data
