Siemens SINUMERIK 840D Operation/Programming

3
10.04 Programming with ShopMill
3.7 Drillin
g
3
 Siemens AG, 2004. All rights reserved
SINUMERIK 840D/840Di/810D Operation/Programming ShopMill (BAS) – 10.04 Edition 3-247
A
Y
Z
∆
Y
A
Y axis is not central above the cylinder ( ∆ Y)
• XYA plane
You program in XYA if the Y axis is required to move during
machining. A value can be specified for each position.
In addition to the possibilities of XA, the following is also possible, for
example.
A
Y
Z
A
Y0 Y1
A
Y axis is traversed (Y0, Y1)
