Programming with G Code 10.04
4.3 G code editor
4
 Siemens AG, 2004. All rights reserved
4-324 SINUMERIK 840D/840Di/810D Operation/Programming ShopMill (BAS) – 10.04 Edition
The G code editor will be opened automatically if you write or open a
G code program.
Selecting G code
 Place the cursor at the position in the program where you want
your selection to start.
Mark
 Press the "Mark" softkey.
 Place the cursor at the position in the program where you want
your selection to end.
The G code is selected.
Copying G code
 Select the G code that you want to copy.
Copy
 Press the "Copy" softkey.
The G code is stored in buffer memory and remains there even if you
switch to another program.
Pasting G code
 Copy the G code that you want to insert.
Insert
 Press the "Insert" softkey.
The copied G code is pasted from buffer memory into the text in front
of the cursor.
Cutting G code
 Select the G code that you want to cut.
Cut
 Press the "Cut" softkey.
The selected G code is removed and stored in buffer memory.
