4
10.04 Programming with G Code
4.3 G code editor
4
ï›™ Siemens AG, 2004. All rights reserved
SINUMERIK 840D/840Di/810D Operation/Programming ShopMill (BAS) – 10.04 Edition 4-325
Finding G code
Search
>
îš¾ Press the "Search" softkey.
A new vertical softkey bar appears.
îš¾ Enter the character string that you want to locate.
îš¾ Press the "OK" softkey.
The G code program is searched for the character string in the
forward direction. The character string is marked in the editor by the
cursor.
Continue
search
îš¾ Press the "Find next" softkey if you want to continue the search.
The next character string found is displayed.
Finding and replacing G
code
Search
>
îš¾ Press the "Search" softkey.
A new vertical softkey bar appears.
Search/
Replace
îš¾ Press the "Search/Replace" softkey.
îš¾ Enter the character string that you want to find and the characters
that you want to insert in its place.
îš¾ Press the "OK" softkey.
The G code program is searched for the character string in the
forward direction. The character string is marked in the editor by the
cursor.
Replace
all
îš¾ Press the "Replace all" softkey if you want to replace the
character string throughout the entire G code program.
-or-
Find next
îš¾ Press the "Find next" softkey if you want to continue the search
without replacing the instance of the character string found.
-or-
Replace
îš¾ Press the "Replace" softkey if you want to replace the character
string at this point in the G code program.
