8
10.04 Alarms and Messages
8.1 C
cle alarms and messa
es
8
ï›™ Siemens AG, 2004. All rights reserved
SINUMERIK 840D/840Di/810D Operation/Programming ShopMill (BAS) – 10.04 Edition 8-399
61102 "No spindle direction programmed" A spindle direction must be programmed
61103 "Number of holes is zero" No value has been programmed for the number
of holes
61104 "Contour violation of slots" Errors in parameterization of milling pattern in
those parameters which define the position of
slots on a circle and their shape
61105 "Cutter radius too large" The diameter of the milling cutter being used is
too large for the figure that is to be machined;
either a tool with a smaller radius must be used
or the contour must be changed
61106 "Number or spacing of circle
elements"
Parameterization error, programmed circle
elements cannot be arranged around a full
circle
61107 "First drilling depth incorrectly
defined"
First drilling depth is inverted in relation to total
drilling depth.
61108 "No valid settings for parameters
RAD1 and _DP1"
Parameters "Radius" and "Infeed depth per
revolution" must be taken into account for
insertion along helical path
61109 "Parameter _CDIR incorrectly
defined"
Parameter defining milling direction is
incorrectly defined
61110 "Finishing allowance on base >
infeed depth"
Alter setting for depth infeed, if necessary.
61111 "Infeed width > tool diameter" The programmed infeed width is greater than
the diameter of the active tool. The infeed width
must be reduced.
61112 "Tool radius negative" The radius of the active tool is negative. This is
illegal.
61113 "Parameter _CRAD for corner
radius too large"
Reduce the parameter for corner radius
61114 "Direction of machining G41/G42
incorrectly defined"
Check the machining direction of tool radius
compensation left/right and alter.
61115 "Approach or retract mode
(line/circle/plane/
space) incorrectly defined"
An incorrect contour approach or retract mode
was defined. Check the approach/retract mode
or approach/retract strategy parameter.
61116 "Approach or retract path = 0" The approach or retract path is set to zero, it
must be increased.
61117 "Active tool radius <= 0" The radius of the active tool is negative or zero.
This is illegal.
61118 "Length or width = 0" The length or width of the milling surface is
illegal.
61119 "Nominal or core diameter
incorrectly programmed"
Check thread geometry
61120 "Thread type internal, external not
defined"
You must enter the internal, external thread
type.
