8
Alarms and Messages 10.04
8.1 C
cle alarms and messa
es
8
ï›™ Siemens AG, 2004. All rights reserved
8-400 SINUMERIK 840D/840Di/810D Operation/Programming ShopMill (BAS) – 10.04 Edition
61121 "Number of teeth/cutting edge
missing"
Enter the number of teeth/cutting edges for the
active tool into the tool list.
61122 "Safety clearance in the plane
incorrectly defined"
The safety clearance is negative or zero. This is
illegal.
61124 "Infeed width is not programmed" In active simulation without a tool, a value for
the infeed width must always be pro-
grammed.
61125 "Technology selection in
parameter _TECHNO incorrectly
defined"
Check settings in machine data 9855 and 9856.
61126 "Thread length too short" Check thread geometry.
61127 "Speed ratio of tapping axis
incorrectly defined (machine data)"
Check settings in machine data 31050 and
31060.
61128 "Insertion angle = 0 for insertion
via oscillation or helix"
Use larger insertion angle.
61180 "No name assigned to swivel data
block although machine data
$MN_MM_NUM_TOOL_CARRIER
> 1"
Assign a unique name for the swivel data block.
61181 "NCK software version too old
(no TOOLCARRIER functionality)"
Upgrade NCK software.
61182 "Name of swivel data record
unknown"
Check the name of the swivel data block.
61183 "Retraction mode GUD7 _TC_FR
outside value range 0..2"
Check installation and start-up of the swivel
cycle CYCLE800.
61184 "No solution can be found with
current angle inputs"
Check the angle entered for the swivelling of
the machining plane.
61185 "No or incorrect (min > max)
angle ranges declared for rotary
axes"
Check installation and start-up of the swivel
cycle CYCLE800.
61186 "Invalid rotary axis vectors" Check installation and start-up of the swivel
cycle CYCLE800.
61188 "No axis name declared for 1st
rotary axis -> check CYCLE800
start-up"
Check installation and start-up of the swivel
cycle CYCLE800.
61200 "Too many elements in machining
block"
Revise machining block, if necessary deleting
elements
61201 "Incorrect sequence in machining
block"
Sort the machining block sequence.
61202 "Not a technology cycle" Program technology block.
