Siemens SINUMERIK 840D Operation/Programming

9
10.04 Examples
9.2 Exam
p
le 2: Translation and mirrorin
g
of a contour
9
 Siemens AG, 2004. All rights reserved
SINUMERIK 840D/840Di/810D Operation/Programming ShopMill (BAS) – 10.04 Edition 9-427
1.
X 60 abs R 3
2.
X 10 abs Y 40 abs R 3
3.
X 10 abs Y 10 abs R 3
• Press the
softkey.
4. Remove stock
• Select via the
Remove
stock >
softkeys
• Assign technological parameters T, F and S accordingly (e.g.
cutter diameter 3) and enter the following parameters:
Machining
Z0
0 abs
Z1
10 inc.
DXY
1.5 mm
DZ
2
UXY
0.5
UZ
0.5
Start point
Auto
Insertion
Center
FZ
0.1 mm/tooth
Retraction mode
Select the mode, e.g. to retraction plane
•
5. Set end marker for contour
repetition
• Select via the
Set
marker >
softkeys
• Set end marking with "Marker2"
•
6. Translate
• Select via the
Transfor-
mations >
Offset
>
softkeys
• Set the following parameters:
New/additive
New
X
120
Y
60
Z
0
•
7. Mirror
• Select via the
Transfor-
mations >
Mirror
>
softkeys
• Set the following parameters:
