Terminals
Overview of Terminals
[dwio201p-030211-01.tif, 2, --_--]
Figure 3-18
IO201 – Terminals
(1) Current terminal xA
(2) Voltage terminal xB
(3) Voltage terminal xC
(4) Voltage terminal xD
(5) Protective grounding terminals
i
i
NOTE
x corresponds to the slot in the 19-inch rack.
3.2.2.2
Electronic Modules
3.2 Input and Output Modules of the Modular Devices
64 SIPROTEC 5, Hardware Description, Manual
C53000-G5040-C002-M, Edition 12.2021
