Siemens siprotec 7SA522 User Manual

2 Functions
114
7SA522 Manual
C53000-G1176-C155-3
2.3.3 Settings
2.3.4 Information List
Addr. Parameter Setting Options Default Setting Comments
2002 P/S Op. mode All zones block
Z1/Z1B block
Z2 to Z5 block
Z1,Z1B,Z2 block
All zones block Power Swing Operating mode
2006 PowerSwing trip NO
YES
NO Power swing trip
2007 Trip DELAY P/S 0.08 .. 5.00 sec; 0 0.08 sec Trip delay after Power Swing
Blocking
No. Information Type of In-
formation
Comments
4160 >Pow. Swing BLK SP >BLOCK Power Swing detection
4163 P.Swing unstab. OUT Power Swing unstable
4164 Power Swing OUT Power Swing detected
4166 Pow. Swing TRIP OUT Power Swing TRIP command
4167 Pow. Swing L1 OUT Power Swing detected in L1
4168 Pow. Swing L2 OUT Power Swing detected in L2
4169 Pow. Swing L3 OUT Power Swing detected in L3
