Siemens siprotec 7SA522 User Manual

2 Functions
358
7SA522 Manual
C53000-G1176-C155-3
2.21.6 Set Points (Measured Values)
To recognize extraordinary operational conditions, warning levels can be pro-
grammed. When exceeding (with cos ϕ: undershooting) a programmed limit value a
message is generated that can be allocated to both output relays and LEDs. In con-
trast to the actual protection functions the monitoring function operates in the back-
ground; therefore it may not pick up if measured values are changed spontaneously
in the event of a fault and if protection functions are picked up. Also, monitoring does
not respond immediately before a trip because an alarm is only output if the setpoint
are repeatedly violated.
860 UL1EMax= MVT U L1E Maximum
861 UL2EMin= MVT U L2E Minimum
862 UL2EMax= MVT U L2E Maximum
863 UL3EMin= MVT U L3E Minimum
864 UL3EMax= MVT U L3E Maximum
865 UL12Min= MVT U L12 Minimum
867 UL12Max= MVT U L12 Maximum
868 UL23Min= MVT U L23 Minimum
869 UL23Max= MVT U L23 Maximum
870 UL31Min= MVT U L31 Minimum
871 UL31Min= MVT U L31 Maximum
874 U1 Min = MVT U1 (positive sequence) Voltage Minimum
875 U1 Max = MVT U1 (positive sequence) Voltage Maximum
880 SMin= MVT Apparent Power Minimum
881 SMax= MVT Apparent Power Maximum
882 fMin= MVT Frequency Minimum
883 fMax= MVT Frequency Maximum
1040 Pmin Forw= MVT Active Power Minimum Forward
1041 Pmax Forw= MVT Active Power Maximum Forward
1042 Pmin Rev = MVT Active Power Minimum Reverse
1043 Pmax Rev = MVT Active Power Maximum Reverse
1044 Qmin Forw= MVT Reactive Power Minimum Forward
1045 Qmax Forw= MVT Reactive Power Maximum Forward
1046 Qmin Rev = MVT Reactive Power Minimum Reverse
1047 Qmax Rev = MVT Reactive Power Maximum Reverse
1048 PFminForw= MVT Power Factor Minimum Forward
1049 PFmaxForw= MVT Power Factor Maximum Forward
1050 PFmin Rev= MVT Power Factor Minimum Reverse
1051 PFmax Rev= MVT Power Factor Maximum Reverse
10102 3U0min = MVT Min. Zero Sequence Voltage 3U0
10103 3U0max = MVT Max. Zero Sequence Voltage 3U0
No. Information Type of In-
formation
Comments
