4 Technical Data
460
7SA522 Manual
C53000-G1176-C155-3
4.7 Weak-Infeed Tripping (classic)
Operating Mode
Undervoltage
Times
Phase segregated undervoltage detection after reception of a carrier signal from the remote end
Set value U
PhE
< 2 V to 70 V Increments 1 V
Drop-off to pick-up ratio Approx. 1.1
Pick-up tolerance ≤ 5 % of setting value, or 0.5 V
Enable delay 0.00 s to 30.00 s Increments 0.01 s
Enable delay 0.00 s to 30.00 s Increments 0.01 s
Echo blocking duration after echo 0.00 s to 30.00 s Increments 0.01 s
Pick-up tolerance 1 % of setting value or 10 ms
