3 Mounting and Commissioning
372
7SA522 Manual
C53000-G1176-C155-3
3.1 Mounting and Connections
General
WARNING!
Warning of improper transport, storage, installation, and application of the
device.
Non–observance can result in death, personal injury or substantial property damage.
Trouble free and safe use of this device depends on proper transport, storage, instal-
lation, and application of the device according to the warnings in this instruction
manual.
Of particular importance are the general installation and safety regulations for work in
a high-voltage environment (for example, VDE, IEC, EN, DIN, or other national and
international regulations). These regulations must be observed.
3.1.1 Configuration Information
Prerequisites For installation and connections the following conditions must be met:
The rated device data is checked as recommended in the SIPROTEC
®
4 System De-
scription. The compliance of these data is verified with the Power System Data.
Connection Vari-
ants
General Diagrams are shown in Appendix A.2. Connection examples for current trans-
former and voltage transformer circuits are provided in Appendix A.3. It must be
checked that the setting of the 36\VWHP'DWD, Section 2.1.3.1, was made in ac-
cordance to the device connections.
Currents In Appendix A.3 examples for the possibilities of the current transformer connections
in dependence on network conditions are displayed.
For normal connection, address ,WUDQVIRUPHU = ,QSURWOLQH must be
set and furthermore, address ,,SK&7 = .
When using separate earth current transformers, address ,WUDQVIRUPHU =
,QSURWOLQH must be set. The factor ,,SK&7 may deviate from . For
calculation hints, please refer to Section 2.1.3.1 at “Current Transformer Connection”.
Please observe that 2-CT-connection is permitted only for isolated or compensated
networks.
Furthermore, examples for the connection of the earth current of a parallel line (for par-
allel line compensation) are displayed. Address ,WUDQVIRUPHU must be set
,QSDUDOOLQH here. The factor ,,SK&7 may deviate from . For calcu-
lation hints, please refer to Section 2.1.3.1.
The other figures show examples for the connection of the earth current of a source
transformer. Address ,WUDQVIRUPHU must be set ,<VWDUSRLQW here. Hints
regarding the factor ,,SK&7 can also be found in Section 2.1.3.1.
