2.1 General
61
7SA522 Manual
C53000-G1176-C155-3
is also the extent of a fault recording (address :$9()250'$7$ = )DXOW
HYHQW). If automatic reclosure is implemented, the entire system disturbance — pos-
sibly with several reclose attempts — up to the ultimate fault clearance can be stored
(address :$9()250'$7$ = 3RZ6\V)OW). This facilitates the representation
of the entire system fault history, but also consumes storage capacity during the auto-
reclosure dead time(s). This setting is only possible via DIGSI
®
at Additional Set-
tings.
The actual storage time encompasses the pre-fault time 35(75,*7,0( (address
) ahead of the reference instant, the normal recording time and the post-fault time
32675(&7,0( (address ) after the storage criterion has reset. The maximum
length of time of a fault record 0$;/(1*7+ is entered in Address .
The fault recording can also be triggered via a binary input, via the keypad on the front
of the device or with a PC via the operation or service interface. The storage is then
dynamically triggered. The length of the fault recording is set in address %LQ,Q
&$377,0( (maximum length however is 0$;/(1*7+, address ). Pre-fault and
post-fault times will be included. If the binary input time is set for ∞, then the length of
the record equals the time that the binary input is activated (static), or the 0$;
/(1*7+ setting in address , whichever is shorter.
2.1.6.3 Settings
Addresses which have an appended "A" can only be changed with DIGSI, under Ad-
ditional Settings.
2.1.6.4 Information List
Addr. Parameter Setting Options Default Setting Comments
402A WAVEFORMTRIGGE
R
Save w. Pickup
Save w. TRIP
Start w. TRIP
Save w. Pickup Waveform Capture
403A WAVEFORM DATA Fault event
Pow.Sys.Flt.
Fault event Scope of Waveform Data
410 MAX. LENGTH 0.30 .. 5.00 sec 2.00 sec Max. length of a Waveform
Capture Record
411 PRE. TRIG. TIME 0.05 .. 0.50 sec 0.25 sec Captured Waveform Prior to
Trigger
412 POST REC. TIME 0.05 .. 0.50 sec 0.10 sec Captured Waveform after Event
415 BinIn CAPT.TIME 0.10 .. 5.00 sec; ∞ 0.50 sec Capture Time via Binary Input
No. Information Type of In-
formation
Comments
- FltRecSta IntSP Fault Recording Start
4 >Trig.Wave.Cap. SP >Trigger Waveform Capture
203 Wave. deleted OUT_Ev Waveform data deleted
