A.4 Default Settings
521
7SA522 Manual
C53000-G1176-C155-3
A.4.4 Function Keys
Table A-4 Applies to All Devices and Ordered Variants
BO10 DisTRIP3p. Z1sf 3823 DisTRIP 3phase in Z1 with single-ph
Flt.
DisTRIP3p.Z1Bsf 3825 DisTRIP 3phase in Z1B with single-
ph Flt
BO11 DisTRIP3p. Z1mf 3824 DisTRIP 3phase in Z1 with multi-ph
Flt.
DisTRIP3p Z1Bmf 3826 DisTRIP 3phase in Z1B with multi-ph
Flt.
BO12 Alarm Sum Event 160 Alarm Summary Event
BO13 Relay TRIP 511 Relay GENERAL TRIP command
Relay TRIP 1pL1 512 Relay TRIP command - Only Phase
L1
Relay TRIP 3ph. 515 Relay TRIP command Phases L123
BO14 Relay TRIP 511 Relay GENERAL TRIP command
Relay TRIP 1pL2 513 Relay TRIP command - Only Phase
L2
Relay TRIP 3ph. 515 Relay TRIP command Phases L123
BO15 Relay TRIP 1pL3 514 Relay TRIP command - Only Phase
L3
Relay TRIP 3ph. 515 Relay TRIP command Phases L123
Binary Output Short Text Function No. Description
Function Keys Short Text Function No. Description
F1 Display of Opera-
tional Annuncia-
tions
--
F2 Operating Mea-
sured Values,
Primary
--
F3 An Overview of the
Last Eight Network
Faults
--
F4 not allocated - -
