2.22 Command processing
367
7SA522 Manual
C53000-G1176-C155-3
Figure 2-164 Example of Configured Interlocking Conditions
Control Logic via
CFC
For the bay interlocking an enabling logic can be structured using the CFC. Via spe-
cific release conditions the information “released” or “bay interlocked” are available.
ON / OFF).
2.22.1.4 Information List
2.22.2 Control Device
2.22.2.1 Information List
No. Information Type of In-
formation
Comments
- ModeREMOTE IntSP Controlmode REMOTE
- CntrlDIGSI LV Control DIGSI
- Cntrl Auth IntSP Control Authority
- ModeLOCAL IntSP Controlmode LOCAL
No. Information Type of In-
formation
Comments
- Breaker CF_D12 Breaker
- Breaker DP Breaker
- Disc.Swit. CF_D2 Disconnect Switch
- Disc.Swit. DP Disconnect Switch
- EarthSwit CF_D2 Earth Switch
- EarthSwit DP Earth Switch
- 52 Open IntSP Interlocking: 52 Open
- 52 Close IntSP Interlocking: 52 Close
- Disc.Open IntSP Interlocking: Disconnect switch Open
- Disc.Close IntSP Interlocking: Disconnect switch Close
- E Sw Open IntSP Interlocking: Earth switch Open
- E Sw Cl. IntSP Interlocking: Earth switch Close
- Q2 Op/Cl CF_D2 Q2 Open/Close
- Q2 Op/Cl DP Q2 Open/Close
- Q9 Op/Cl CF_D2 Q9 Open/Close
- Q9 Op/Cl DP Q9 Open/Close
