A.10 Measured Values
585
7SA522 Manual
C53000-G1176-C155-3
A.10 Measured Values
No. Description Function IEC 60870-5-103 Configurable in Matrix
Type
Information Number
Compatibility
Data Unit
Position
CFC
Control Display
Default Display
- Control DIGSI (CntrlDIGSI) Cntrl Authority - - - - - CFC CD DD
- Upper setting limit for IL1dmd (IL1dmd>) Set Points(MV) - - - - - CFC CD DD
- Upper setting limit for IL2dmd (IL2dmd>) Set Points(MV) - - - - - CFC CD DD
- Upper setting limit for IL3dmd (IL3dmd>) Set Points(MV) - - - - - CFC CD DD
- Upper setting limit for I1dmd (I1dmd>) Set Points(MV) - - - - - CFC CD DD
- Upper setting limit for Pdmd (|Pdmd|>) Set Points(MV) - - - - - CFC CD DD
- Upper setting limit for Qdmd (|Qdmd|>) Set Points(MV) - - - - - CFC CD DD
- Upper setting limit for Sdmd (Sdmd>) Set Points(MV) - - - - - CFC CD DD
- Lower setting limit for Power Factor (PF<) Set Points(MV) - - - - - CFC CD DD
601 I L1 (IL1 =) Measurement 128 148 Yes 9 1 CFC CD DD
134 129 No 9 1
602 I L2 (IL2 =) Measurement 128 148 Yes 9 2 CFC CD DD
134 129 No 9 2
603 I L3 (IL3 =) Measurement 128 148 Yes 9 3 CFC CD DD
134 129 No 9 3
610 3I0 (zero sequence) (3I0 =) Measurement - - - - - CFC CD DD
611 3I0sen (sensitive zero sequence) (3I0sen=) Measurement - - - - - CFC CD DD
612 IY (star point of transformer) (IY =) Measurement - - - - - CFC CD DD
613 3I0par (parallel line neutral) (3I0par=) Measurement - - - - - CFC CD DD
619 I1 (positive sequence) (I1 =) Measurement - - - - - CFC CD DD
620 I2 (negative sequence) (I2 =) Measurement - - - - - CFC CD DD
621 U L1-E (UL1E=) Measurement 128 148 Yes 9 4 CFC CD DD
134 129 No 9 4
622 U L2-E (UL2E=) Measurement 128 148 Yes 9 5 CFC CD DD
134 129 No 9 5
623 U L3-E (UL3E=) Measurement 128 148 Yes 9 6 CFC CD DD
134 129 No 9 6
624 U L12 (UL12=) Measurement 134 129 No 9 10 CFC CD DD
625 U L23 (UL23=) Measurement 134 129 No 9 11 CFC CD DD
626 U L31 (UL31=) Measurement 134 129 No 9 12 CFC CD DD
627 Uen (Uen =) Measurement - - - - - CFC CD DD
631 3U0 (zero sequence) (3U0 =) Measurement - - - - - CFC CD DD
632 Usync (synchronism) (Usync =) Measurement - - - - - CFC CD DD
633 Ux (separate VT) (Ux =) Measurement - - - - - CFC CD DD
634 U1 (positive sequence) (U1 =) Measurement - - - - - CFC CD DD
635 U2 (negative sequence) (U2 =) Measurement - - - - - CFC CD DD
636 U-diff (line-bus) (Udiff =) Measurement 130 1 No 9 2 CFC CD DD
637 U-line (Uline =) Measurement 130 1 No 9 3 CFC CD DD
638 U-bus (Ubus =) Measurement 130 1 No 9 1 CFC CD DD
641 P (active power) (P =) Measurement 128 148 Yes 9 7 CFC CD DD
134 129 No 9 7
642 Q (reactive power) (Q =) Measurement 128 148 Yes 9 8 CFC CD DD
134 129 No 9 8
