2.8 Teleprotection for earth fault overcurrent protection (optional)
193
7SA522 Manual
C53000-G1176-C155-3
The preset value should be sufficient in most cases.
Echo Function In the case of line ends with weak infeed, or not sufficient earth current, the echo func-
tion is sensible for the permissive scheme so that the infeeding line end can be re-
leased. The echo function at address  )&7:HDN,QIHHG can be activated
((&+2RQO\) or deactivated (2))). By means of this “switch” the weak infeed tripping
function can also be activated ((&+2DQG75,3, refer also to Section 2.9.1).
Please do not fail do read the comments regarding the setting of the current stage
,R0LQ7HOHSURW (address ) in the above margin heading “Earth Fault Pro-
tection Prerequisites”.
The echo delay time 7ULS(FKR'(/$< (address ) must be set long enough to
avoid incorrect echo signals resulting from the difference in fault detection pick-up time
of the earth fault protection functions at all line ends during external faults (through-
fault current). Typical setting is approx. 40 ms (presetting). This setting is only possible
via DIGSI
®
at Additional Settings.
The echo impulse duration 7ULS(;7(16,21 (address ) may be matched to the
configuration data of the signal transmission equipment. It must be long enough to
ensure that the receive signal is recognized even with different pick-up times by the
protection devices at the two line ends and different response times of the transmis-
sion equipment. In most cases approx. 50 ms (presetting) is sufficient. This setting is
only possible via DIGSI
®
at Additional Settings.
An endless echo signal between the line ends can be avoided (e.g. interference cou-
pling in the signal path) by blocking after each output of an echo signal a new echo for
a certain time (FKR%/2&.7LPH (address ). The typical setting is approx. 50
ms. After the earth fault protection signal was sent, the echo is equally blocked for the
time (FKR%/2&.7LPH. This setting is only possible via DIGSI
®
at Additional Set-
tings.
If the distance protection and earth fault protection use a common transmission chan-
nel, spurious tripping may occur when the distance protection and the earth fault pro-
tection create an echo independently of each other. For this scenario, parameter
(FKRFKDQQHO (address ) must be set to <(6. The default setting is 12.
Note
The ´(&+26,*1$/µ (FNo 4246) must be allocated separately to the output relays
for the transmitter actuation, as it is not contained in the transmit signals of the trans-
mission functions. On the digital protection data interface with permissive overreach
transfer trip mode, the echo is transmitted as a separate signal without taking any
special measures.
The echo function settings are common to all weak infeed measures and summarized
in tabular form in Section 2.9.1.
