2.8 Teleprotection for earth fault overcurrent protection (optional)
195
7SA522 Manual
C53000-G1176-C155-3
1380 EF TeleON/offBI IntSP E/F Teleprot. ON/OFF via BI
1381 EF Telep. OFF OUT E/F Teleprotection is switched OFF
1384 EF Tele SEND OUT E/F Telep. Carrier SEND signal
1386 EF TeleTransBlk OUT E/F Telep. Transient Blocking
1387 EF TeleUB Fail1 OUT E/F Telep. Unblocking: FAILURE Channel 1
1388 EF TeleUB Fail2 OUT E/F Telep. Unblocking: FAILURE Channel 2
1389 EF Tele BL STOP OUT E/F Telep. Blocking: carrier STOP signal
1390 EF Tele BL Jump OUT E/F Tele.Blocking: Send signal with jump
1391 EF Rec.L1 Dev1 OUT EF Tele.Carrier RECEPTION, L1, Device1
1392 EF Rec.L2 Dev1 OUT EF Tele.Carrier RECEPTION, L2, Device1
1393 EF Rec.L3 Dev1 OUT EF Tele.Carrier RECEPTION, L3, Device1
1394 EF Rec.L1 Dev2 OUT EF Tele.Carrier RECEPTION, L1, Device2
1395 EF Rec.L2 Dev2 OUT EF Tele.Carrier RECEPTION, L2, Device2
1396 EF Rec.L3 Dev2 OUT EF Tele.Carrier RECEPTION, L3, Device2
1397 EF Rec.L1 Dev3 OUT EF Tele.Carrier RECEPTION, L1, Device3
1398 EF Rec.L2 Dev3 OUT EF Tele.Carrier RECEPTION, L2, Device3
1399 EF Rec.L3 Dev3 OUT EF Tele.Carrier RECEPTION, L3, Device3
No. Information Type of In-
formation
Comments
