2.14 Synchronism and voltage check (optional)
267
7SA522 Manual
C53000-G1176-C155-3
The five possible release conditions are independent of each other and can be com-
bined.
Note
The closing functions of the device issue individual output indications for the corre-
sponding close command. Be sure that the output indications are assigned to the
correct output relays.
FNo 2851 ´$5&/26(&PGµ for CLOSE command of the automatic reclosure,
FNo 562 ´0DQ&ORVH&PGµ for manual CLOSE via binary input,
FNo 2961 ´6\QF&ORVH&PGµ for CLOSE by synchronism check (not required if syn-
chronism check releases the other CLOSE commands),
FNo 7329 ´&%î˜7(67FORVHµ for CLOSE via circuit breaker test,
additionally CLOSE command via control e.g. ´&ORVHµ,
FNo 510 ´5HOD\&/26(µ general CLOSE command for all CLOSE commands de-
scribed above.
Notes on the Infor-
mation List
The most important information of the device is briefly explained in so far as it cannot
be interpreted in the following information lists or described in detail in the foregoing
text.
´!6\QF6WDUW0&µ (FNo. 2905)
Binary input which enables direct tripping of the sychnonism check with setting param-
eters for manual close. This tripping with setting parameter for manual close has
always precedence if binary inputs ´!6\QF6WDUW0&µ (F.No. 2905) and ´!6\QF
6WDUW$5µ (F.No. 2906, see below) are activated at the same time.
´!6\QF6WDUW$5µ (FNo. 2906)
Measuring request from an external automatic reclosure device. The parameters of
synchronism check set for automatic reclosure are valid here.
´6\QFUHT&175/µ (FNo. 2936)
Measurement request of the control function; this request is evaluated on event-trig-
gered basis and only generated if the control issues a measurement request.
´6\QFUHOHDVHµ (FNo. 2951)
Release signal to an external automatic reclosure device.
