2.15 Undervoltage and overvoltage protection (optional)
287
7SA522 Manual
C53000-G1176-C155-3
10272 3U0> TimeOut OUT 3U0> TimeOut
10273 3U0>> TimeOut OUT 3U0>> TimeOut
10274 3U0>(>) TRIP OUT 3U0>(>) TRIP command
10280 U1> Pickup OUT U1> Pickup
10281 U1>> Pickup OUT U1>> Pickup
10282 U1> TimeOut OUT U1> TimeOut
10283 U1>> TimeOut OUT U1>> TimeOut
10284 U1>(>) TRIP OUT U1>(>) TRIP command
10290 U2> Pickup OUT U2> Pickup
10291 U2>> Pickup OUT U2>> Pickup
10292 U2> TimeOut OUT U2> TimeOut
10293 U2>> TimeOut OUT U2>> TimeOut
10294 U2>(>) TRIP OUT U2>(>) TRIP command
10300 U1< Pickup OUT U1< Pickup
10301 U1<< Pickup OUT U1<< Pickup
10302 U1< TimeOut OUT U1< TimeOut
10303 U1<< TimeOut OUT U1<< TimeOut
10304 U1<(<) TRIP OUT U1<(<) TRIP command
10310 Uph-e< Pickup OUT Uph-e< Pickup
10311 Uph-e<< Pickup OUT Uph-e<< Pickup
10312 Uph-e<(<) PU L1 OUT Uph-e<(<) Pickup L1
10313 Uph-e<(<) PU L2 OUT Uph-e<(<) Pickup L2
10314 Uph-e<(<) PU L3 OUT Uph-e<(<) Pickup L3
10315 Uph-e< TimeOut OUT Uph-e< TimeOut
10316 Uph-e<< TimeOut OUT Uph-e<< TimeOut
10317 Uph-e<(<) TRIP OUT Uph-e<(<) TRIP command
10325 Uph-ph< Pickup OUT Uph-ph< Pickup
10326 Uph-ph<< Pickup OUT Uph-ph<< Pickup
10327 Uphph<(<)PU L12 OUT Uphph<(<) Pickup L1-L2
10328 Uphph<(<)PU L23 OUT Uphph<(<) Pickup L2-L3
10329 Uphph<(<)PU L31 OUT Uphph<(<) Pickup L3-L1
10330 Uphph< TimeOut OUT Uphph< TimeOut
10331 Uphph<< TimeOut OUT Uphph<< TimeOut
10332 Uphph<(<) TRIP OUT Uphph<(<) TRIP command
No. Information Type of In-
formation
Comments
