4897SA522 Manual
C53000-G1176-C155-3
Appendix A
This appendix is primarily a reference for the experienced user. This section provides
ordering information for the models of this device. General diagrams indicating the ter-
minal connections of the models of this device are included. Following the general di-
agrams are diagrams that show the proper connections of the devices to primary
equipment in many typical power system configurations. Tables with all settings and
all information available in this device equipped with all options are provided. Default
settings are also given.
A.1 Ordering Information and Accessories 490
A.2 Terminal Assignments 498
A.3 Connection Examples 512
A.4 Default Settings 519
A.5 Protocol-dependent Functions 527
A.6 Functional Scope 528
A.7 Settings 530
A.8 Information List 546
A.9 Group Alarms 584
A.10 Measured Values 585
