A.6 Functional Scope
529
7SA522 Manual
C53000-G1176-C155-3
134 AR control mode Pickup w/ Tact
Pickup w/o Tact
Trip w/ Tact
Trip w/o Tact
Trip w/ Tact Auto-Reclose control mode
135 Synchro-Check Disabled
Enabled
Disabled Synchronism and Voltage Check
136 FREQUENCY Prot. Disabled
Enabled
Disabled Over / Underfrequency Protection
137 U/O VOLTAGE Disabled
Enabled
Enabl. w. comp.
Disabled Under / Overvoltage Protection
138 Fault Locator Enabled
Disabled
Enabled Fault Locator
139 BREAKER FAILURE Disabled
Enabled
Disabled Breaker Failure Protection
140 Trip Cir. Sup. Disabled
1 trip circuit
2 trip circuits
3 trip circuits
Disabled Trip Circuit Supervision
145 P. INTERFACE 1 Enabled
Disabled
Enabled Protection Interface 1 (Port D)
146 P. INTERFACE 2 Disabled
Enabled
Disabled Protection Interface 2 (Port E)
147 NUMBER OF RELAY 2 relays
3 relays
2 relays Number of relays
Addr. Parameter Setting Options Default Setting Comments
