7.11 Identification data for PROFINET IO
Power supply system SITOP PSU8600
354 Manual, 09.2018, A5E36758446-5-76
7.11
Identification data for PROFINET IO
I&M data
Access
Default setting
Explanation
Identification data 0: (data set index AFF0 hex)
VendorIDHigh Read (1 byte) 00 hex The name of the manufacturer is saved
here (42 = SIEMENS AG).
VendorIDLow
Read (1 byte)
2A hex
Order_ID Read (20 byte) Order number of the module
IM_SERIAL_NUMBER
Read (16 byte)
-
Serial number (device-specific)
IM_HARDWARE_REVISION
Read (2 byte)
1
Corresponding to the HW version
IM_SOFTWARE_REVISION
Read
Firmware version
Provides information about the firmware
version of the module
• SWRevisionPrefix
(1 byte) V, R, P, U, T
• IM_SWRevision_Functional_
Enhancement
(1 byte) 00 - FF hex
• IM_SWRevision_Bug_Fix
(1 byte) 00 - FF hex
• IM_SWRevision_Internal_
Change
(1 byte) 00 - FF hex
IM_REVISION_COUNTER Read (2 byte) - Provides information about parameter
changes on the module
(not used)
IM_PROFILE_ID
Read (2 byte)
0000
Generic Device
IM_PROFILE_SPECIFIC_TYPE
Read (2 byte)
0005 hex
On interface modules
IM_VERSION
Read
0101 hex Provides information on the version of the
identification data
(0101 hex = Version 1.1)
• IM_Version_Major
(1 byte)
• IM_Version_Minor
(1 byte)
IM_SUPPORTED Read (2 byte) 000E hex Provides information about the available
identification data (I&M1 to I&M3)
Maintenance data 1: (data set index AFF1 hex)
IM_TAG_FUNCTION Read/write (32
bytes)
- Enter a module identifier here that is unique
plant-wide.
IM_TAG_LOCATION Read/write (22
bytes)
- Enter the installation location of the module
here.
Maintenance data 2: (data set index AFF2 hex)
IM_DATE Read/write (16
bytes)
YYYY-MM-DD HH:MM Enter the installation date of the module
here.
Maintenance data 3: (data set index AFF3 hex)
IM_DESCRIPTOR Read/write (54
bytes)
- Enter a comment describing the module
here.
