Siemens SITOP PSU8600 User Manual

Technical data
9.7 Mechanical system
Power supply system SITOP PSU8600
Manual, 09.2018, A5E36758446-5-76
399
Expansion modules
Expansion module
6EP4436-8XB00-0CY0
Expansion module
6EP4437-8XB00-0CY0
Expansion module
6EP4436-8XB00-0DY0
Connection system
Plug-in terminals with screw connection
Connections: Line input
-
-
-
Connections: Output 1, 2, 3, 4: 1 screw terminal
each for 0.2 - 2.5 mm
2
GROUND: 3 screw terminals
for 0.2 - 2.5 mm
2
1, 2, 3, 4: 1 screw terminal
each for 0.2 - 2.5 mm
2
GROUND: 3 screw terminals
for 0.2 - 2.5 mm
2
1 … 8: 1 screw terminal each
for 0.2 - 2.5 mm
2
GROUND: 3 screw terminals
for 0.2 - 2.5 mm
2
System connection
Integrated connecting plug
Integrated connecting plug
Integrated connecting plug
Width of the housing
60 mm
60 mm
100 mm
Height of the housing
125 mm
125 mm
125 mm
Depth of the housing
150 mm
150 mm
150 mm
Mounting width
60 mm
60 mm
100 mm
Mounting height
225 mm
225 mm
225 mm
Weight, approx.
1.15 kg
1.15 kg
1.29 kg
Product feature of the hous-
ing: Housing that can be
lined up next to one another
Yes Yes Yes
Type of mounting: Wall/panel
mounting
No No No
Type of mounting: Rail
mounting
Yes Yes Yes
Mounting Can be snapped onto stan-
dard EN 60715 35x15
mounting rails
Can be snapped onto stan-
dard EN 60715 35x15
mounting rails
Can be snapped onto stan-
dard EN 60715 35x15
mounting rails
