Technical data
7.17 Fixing distances
SIVACON 8PS - Configuring with LX system
Configuration Manual, 10/2011, A5E02194899-02
155
7.17 Fixing distances
Fixing distances [m] for conventional mechanical load with horizontal installation
System Edgewise busbars Flat busbars
LXA(C)01.. 2 2
LXA(C)02.. 2 2
LXC03.. 2 2
LXA(C)04.. 2 2
LXA(C)05.. 3 2
LXA(C)06.. 3 2
LXA(C)07.. 3 2
LXA(C)08.. 3 2
LXA(C)09.. 3 2
LXA10.. 3 2
7.18 Connection units for non-Siemens distribution boards
The required conductor cross sections for bare copper bars for connection to connection
units for non-Siemens distribution boards.
Number ... Cu bar
width x thickness
System I
e
[A]
1 2 3 4
Compatible LXA/LXC system
LXC(A)01.. 1000 (800)
1)
60 x 10 30 x 10 20 x 10 - LXA01.. and LXC01..
LXC(A)02.. 1250 (1000)
1)
80 x 10 40 x 10 30 x 10 - LXA02.. and LXC02..
LXC03.. 1400 100 x 10 50 x 10 30 x 10 - LXC03..
LXC(A)04.. 1600 (1250)
1)
100 x 10 60 x 10 30 x 10 - LXA04.. and LXC04..
LXA05.. 1600 100 x 10 60 x 10 30 x 10 - LXA05..
LXC05.. 2000 160 x 10 80 x 10 50 x 10 - LXC05..
LXC(A)06.. 2500 (2000)
1)
200 x 10 100 x 10 60 x 10 50 x 10 LXC06.. and LXA06..
LXC(A)07.. 3200 (2500)
1)
- 160 x 10 100 x 10 80 x 10 LXC07.. and LXA07..
LXC(A)08.. 4000 (3200)
1)
- 200 x 10 120 x 10 100 x 10
2)
LXC08.. and LXA08..
LXC(A)09.. 5000 (4000)
1)
- - 200 x 10 160 x 10 LXC09.. and LXA09..
LXA10.. 4500 - - 160 x 10 120 x 10 LXA10..
1)
Connection to LXA systems
2)
In accordance with DIN 43671, Table 1, the maximum continuous current for this copper
cross section is 3980 A.
